Mcpx
What is Mcpx
McpX is a library designed for communication with Mitsubishi Electric PLCs using the MC protocol. It provides a straightforward API that abstracts the complexities of the MC protocol, making it easier for developers to interact with PLCs.
Use cases
Use cases for McpX include monitoring and controlling industrial machines, automating data collection from PLCs, and integrating PLC data into larger software systems for analysis and reporting.
How to use
To use McpX, you can install it via the .NET CLI using the command ‘dotnet add package McpX’ or through the Package Manager in Visual Studio with ‘PM> NuGet\Install-Package McpX’. After installation, you can create an instance of McpX by specifying the PLC’s IP address and port, and then use its methods to read and write data.
Key features
McpX features a simple and user-friendly API, support for multiple platforms including Linux, Windows, and macOS, and the ability to perform batch read and write operations on PLC data. It is compatible with .NET 7.0 and above.
Where to use
McpX can be used in various fields that require automation and control systems, such as manufacturing, building automation, and industrial IoT applications, where communication with Mitsubishi Electric PLCs is necessary.
Clients Supporting MCP
The following are the main client software that supports the Model Context Protocol. Click the link to visit the official website for more information.
Overview
What is Mcpx
McpX is a library designed for communication with Mitsubishi Electric PLCs using the MC protocol. It provides a straightforward API that abstracts the complexities of the MC protocol, making it easier for developers to interact with PLCs.
Use cases
Use cases for McpX include monitoring and controlling industrial machines, automating data collection from PLCs, and integrating PLC data into larger software systems for analysis and reporting.
How to use
To use McpX, you can install it via the .NET CLI using the command ‘dotnet add package McpX’ or through the Package Manager in Visual Studio with ‘PM> NuGet\Install-Package McpX’. After installation, you can create an instance of McpX by specifying the PLC’s IP address and port, and then use its methods to read and write data.
Key features
McpX features a simple and user-friendly API, support for multiple platforms including Linux, Windows, and macOS, and the ability to perform batch read and write operations on PLC data. It is compatible with .NET 7.0 and above.
Where to use
McpX can be used in various fields that require automation and control systems, such as manufacturing, building automation, and industrial IoT applications, where communication with Mitsubishi Electric PLCs is necessary.
Clients Supporting MCP
The following are the main client software that supports the Model Context Protocol. Click the link to visit the official website for more information.
Content
McpX is a library for communicating with Mitsubishi Electric PLCs using the MC protocol.
It features a simple and easy-to-use API, allowing you to communicate without worrying about MC protocol details.
It runs on various platforms, including Linux, Windows, and macOS.
Installation
.NET CLI
dotnet add package McpX
Package Manager(Visual Studio)
PM> NuGet\Install-Package McpX
Example Usage
using McpXLib;
using McpXLib.Enums;
// Connect to PLC by specifying IP and port
using (var mcpx = new McpX("192.168.12.88", 10000))
{
// Read 7000 points starting from M0
bool[] mArr = mcpx.BatchRead<bool>(Prefix.M, "0", 7000);
// Read 7000 words starting from D1000
short[] dArr = mcpx.BatchRead<short>(Prefix.D, "1000", 7000);
// Write 1234 to D0 and 5678 to D1 as signed 32-bit integers
mcpx.BatchWrite<int>(Prefix.D, "0", [1234, 5678]);
}
C# and Visual Basic samples are available here.
Supported Commands
| Name | Description | Synchronous Method | Asynchronous Method |
|---|---|---|---|
| Single Read | Reads a single value from the specified device. | Read<T>(Prefix prefix, string address) |
ReadAsync<T>(Prefix prefix, string address) |
| Single Write | Writes a single value to the specified device. | Write<T>(Prefix prefix, string address, T value) |
WriteAsync<T>(Prefix prefix, string address, T value) |
| Batch Read | Reads multiple consecutive values starting from the specified address. | BatchRead<T>(Prefix prefix, string address, ushort length) |
BatchReadAsync<T>(Prefix prefix, string address, ushort length) |
| Batch Write | Writes an array of values to consecutive device addresses. | BatchWrite<T>(Prefix prefix, string address, T[] values) |
BatchWriteAsync<T>(Prefix prefix, string address, T[] values) |
| Random Read | Reads values from non-consecutive word and double-word addresses. | RandomRead<T1, T2>((Prefix, string)[] wordAddresses, (Prefix, string)[] doubleWordAddresses) |
RandomReadAsync<T1, T2>((Prefix, string)[] wordAddresses, (Prefix, string)[] doubleWordAddresses) |
| Random Write | Writes values to non-consecutive word and double-word addresses. | RandomWrite<T1, T2>(...) |
RandomWriteAsync<T1, T2>(...) |
| Monitor Registration | Registers devices to monitor. | MonitorRegist((Prefix, string)[] wordAddresses, (Prefix, string)[] doubleWordAddresses) |
MonitorRegistAsync((Prefix, string)[] wordAddresses, (Prefix, string)[] doubleWordAddresses) |
| Monitor Read | Reads the latest values from registered monitoring devices. | Monitor<T1, T2>(...) |
MonitorAsync<T1, T2>(...) |
| Remote Password Lock/Unlock | Automatically locks the PLC with the specified remote password when the instance is created and unlocks it when disposed. | McpX(string ip, int port, string? password = null) |
– |
Supported Protocols
- TCP
- UDP
- 3E frame (binary code)
- 3E frame (ASCII code)
- 4E frame (binary code)
- 4E frame (ASCII code)
Roadmap
- [x]
3E frame (ASCII code) support - [x]
4E frame (binary code) support - [x]
4E frame (ASCII code) support - [x]
UDP support
