What is Litmus Mcp Server

The litmus-mcp-server is the official Model Context Protocol (MCP) Server developed by Litmus Automation, enabling interaction between large language models (LLMs) and intelligent systems with Litmus Edge for device configuration, monitoring, and management. It is built on the MCP SDK and follows the Model Context Protocol specifications.

Use cases

Use cases for the litmus-mcp-server include automating device management in smart homes, monitoring industrial IoT devices, and integrating intelligent systems for enhanced operational efficiency.

How to use

To use the litmus-mcp-server, you can quickly launch it using Docker with the command: docker run -d --name litmus-mcp-server -p 8000:8000 ghcr.io/litmusautomation/litmus-mcp-server:main. Further setup can be done through the Cursor IDE or other integrations as specified in the documentation.

Key features

Key features of the litmus-mcp-server include seamless integration with Litmus Edge, support for Server-Sent Events (SSE), and compatibility with various development environments such as Cursor IDE, Claude Desktop, and VS Code/Copilot.

Where to use

The litmus-mcp-server is primarily used in fields involving IoT (Internet of Things) device management, automation systems, and intelligent applications that require device configuration and monitoring.

Litmus MCP Server

The official Litmus Automation Model Context Protocol (MCP) Server enables LLMs and intelligent systems to interact with Litmus Edge for device configuration, monitoring, and management. It is built on top of the MCP SDK and adheres to the Model Context Protocol spec.

Table of Contents

• Getting Started
  • Quick Launch (Docker)
  • Cursor IDE Setup
• API
• Usage
  • Server-Sent Events (SSE)
• Litmus Central
• Integrations
  • Cursor IDE
  • Claude Desktop
  • VS Code / Copilot
  • Windsurf

---

Getting Started

Quick Launch (Docker)

Run the server in Docker:

docker run -d --name litmus-mcp-server -p 8000:8000 ghcr.io/litmusautomation/litmus-mcp-server:main

Cursor IDE Setup

Example mcp.json configuration:

{
  "mcpServers": {
    "litmus-mcp-server": {
      "url": "http://<IP Address>:8000/sse"
    }
  }
}

See the Cursor docs for more info.

---

API

Category	Function Name	Description
Edge System Config	get_current_environment_config	Get current environment configuration used for Litmus Edge connectivity.
	update_environment_config	Update environment variable config for connecting to Litmus Edge.
	get_current_config	Retrieve current Litmus Edge instance configuration.
	update_config	Update configuration of the device or container running Litmus Edge.
DeviceHub	get_litmusedge_driver_list	List supported Litmus Edge drivers.
	get_devicehub_devices	List devices configured in DeviceHub.
	get_devicehub_device_tags	Retrieve tags for a specific DeviceHub device.
	get_current_value_of_devicehub_tag	Get current value of a specific device tag.
	create_devicehub_device	Register a new DeviceHub device. Supports various protocols and templates for register-based data polling.
Device Identity	get_litmusedge_friendly_name	Retrieve the user-friendly name of the device.
	set_litmusedge_friendly_name	Assign or update the friendly name.
LEM Integration	get_cloud_activation_status	Check cloud activation and Litmus Edge Manager (LEM) connection status.
Docker Management	get_all_containers_on_litmusedge	List all containers on Litmus Edge.
	run_docker_container_on_litmusedge	Launch a Docker container via Litmus Edge Marketplace (not the MCP host).
Topic Subscription	get_current_value_on_topic	Subscribe to current values on a Litmus Edge topic. Use global NATS_STATUS = False to unsubscribe.
	get_multiple_values_from_topic	Retrieve multiple values from a topic for plotting or batch access.

---

Usage

Server-Sent Events (SSE)

This server supports the MCP SSE transport for real-time communication.

• Client endpoint: http://<server-ip>:8000/sse
• Default binding: 0.0.0.0:8000/sse
• Communication:
  • Server → Client: Streamed via SSE
  • Client → Server: HTTP POST

---

Litmus Central

Download or try Litmus Edge via Litmus Central.

---

Integrations

Cursor IDE

Add to ~/.cursor/mcp.json or .cursor/mcp.json:

{
  "mcpServers": {
    "litmus-mcp-server": {
      "url": "http://<IP Address>:8000/sse"
    }
  }
}

Cursor docs

---

Claude Desktop

Add to claude_desktop_config.json:

{
  "mcpServers": {
    "litmus-mcp-server": {
      "url": "http://<IP Address>:8000/sse"
    }
  }
}

Anthropic Docs

---

VS Code / GitHub Copilot

Manual Configuration

In VS Code:
Open User Settings (JSON) → Add:

{
  "mcpServers": {
    "litmus-mcp-server": {
      "url": "http://<IP Address>:8000/sse"
    }
  }
}

Or use .vscode/mcp.json in your project.

VS Code MCP Docs

---

Windsurf

Add to ~/.codeium/windsurf/mcp_config.json:

{
  "mcpServers": {
    "litmus-mcp-server": {
      "url": "http://<IP Address>:8000/sse"
    }
  }
}

Windsurf MCP Docs

MCP server registries

• Glama

• MCP.so

---
