FastAPI MCP Server + LangChain Client Example

Example project demonstrating how to expose FastAPI endpoints as Model Context Protocol (MCP) tools using fastapi-mcp. Includes a basic LangChain agent (langchain_client.py) that connects to the local FastAPI server via HTTP/SSE using langchain-mcp-adapters to discover and use the exposed tools.

Prerequisites

Before you begin, ensure you have the following installed:

• Python: Version 3.10 or higher recommended.
• uv: The Python package manager used in this project. (Installation Instructions)
• Node.js and npm: Required for npx (used to run the optional MCP Inspector). You can download Node.js (which includes npm) from nodejs.org.
• Git: For cloning the repository.
• OpenAI API Key: Required for the LangChain client example. You need to set this in a .env file.

This project demonstrates setting up a basic FastAPI application and exposing its endpoints as Model Context Protocol (MCP) tools using the fastapi-mcp library. It also includes a LangChain agent client that connects to and uses these tools, and covers configuring Cursor to connect as well.

Getting Started / How to Run

1. Clone the Repository:

   git clone <your-repo-url>
   cd <repo-directory>


2. Install uv: If you don’t have it, install the uv package manager (see Project Setup below for command).

3. Set up Environment & Install Dependencies:

   uv init # If pyproject.toml doesn't exist
   uv venv # Create virtual environment (.venv)
   # Install all project dependencies
   uv pip install fastapi "uvicorn[standard]" fastapi-mcp langchain-mcp-adapters langgraph langchain-openai python-dotenv


4. Create .env File: Create a file named .env in the project root directory and add your OpenAI API key:

   OPENAI_API_KEY=your_openai_api_key_here


5. Run the FastAPI MCP Server: Open a terminal and run:

   uvicorn main:app --reload --port 8000


   Keep this terminal running.
   (Alternatively, you can use the Python: FastAPI MCP debug configuration defined in .vscode/launch.json within VS Code / Cursor to run the server with the debugger attached.)

6. Run the LangChain Client: Open a second terminal and run:

   uv run python langchain_client.py


   The client will connect to the server, discover tools, and run a query using the agent.

7. (Optional) Test Server with MCP Inspector: Before running the LangChain client, or for more direct testing, you can use the official MCP Inspector tool:

   • Ensure the FastAPI server is running (Step 5).
   • Open another terminal and run: npx @modelcontextprotocol/inspector
     (npx comes with Node.js/npm. If this command fails, ensure Node.js is installed and accessible in your PATH.)
   • In the inspector UI, connect to your server URL: http://127.0.0.1:8000/mcp
   • Navigate to “Tools”, click “List Tools” to see read_root__get and greet_user_greet__name__get.
   • Select a tool, fill parameters (e.g., name for greet_user), and click “Run Tool”.

8. (Optional) Test greet_user with LangChain Client: The greet_user endpoint and the corresponding test query (query2) in langchain_client.py are currently active. Simply run the LangChain client (Step 6) and observe the second part of its execution where it should attempt to greet the user ‘LangChain’.

   • (If you want to disable this test, comment out the @app.get("/greet/{name}") endpoint in main.py and the query2 section in langchain_client.py)

Goal

To build a simple FastAPI server with MCP capabilities for learning and testing purposes, runnable locally and connectable from MCP clients like the Cursor editor’s agent.

Project Setup

1. Package Manager: We used uv, a fast Python package installer and resolver written in Rust.
   • Installation (Windows PowerShell): irm https://astral.sh/uv/install.ps1 | iex
   • Project Initialization: uv init (Creates pyproject.toml)
   • Virtual Environment: uv venv (Creates and manages .venv)
2. Dependencies: Installed using uv:

   # Specific commands used during development (covered by the combined install in Getting Started):
   # uv pip install fastapi "uvicorn[standard]" fastapi-mcp
   # uv pip install langchain-mcp-adapters langgraph langchain-openai python-dotenv


   This installs FastAPI, the Uvicorn ASGI server, fastapi-mcp, LangChain components, and python-dotenv into the .venv virtual environment.

Application (main.py)

A simple FastAPI app was created with endpoints:

• /: Returns a welcome message.
• /greet/{name}: Returns a personalized greeting (currently commented out).

Crucially, the fastapi-mcp integration happens after the FastAPI route definitions:

from fastapi import FastAPI
from fastapi_mcp import FastApiMCP

app = FastAPI(...)

# --- Define FastAPI routes (@app.get, @app.post, etc.) ---
@app.get("/")
async def read_root():
    # ... endpoint logic ...

# --- Initialize and mount fastapi-mcp AFTER routes ---
mcp = FastApiMCP(app)
mcp.mount() # Exposes tools under /mcp by default

Running the Server

• Directly: uvicorn main:app --reload --port 8000
• With Debugger (Cursor/VS Code): A launch.json file was created in .vscode to run the app with the debugger attached.

LangChain Client (langchain_client.py)

• Reads the .env file for the OPENAI_API_KEY.
• Uses langchain-mcp-adapters (MultiServerMCPClient) to connect to the running FastAPI server at http://127.0.0.1:8000/mcp via SSE.
• Automatically discovers tools exposed by the MCP server.
• Creates a LangGraph ReAct agent using the discovered tools and an OpenAI LLM.
• Runs a sample query through the agent.

Cursor Integration (MCP Client)

1. Configuration: A .cursor/mcp.json file was created in the project root:

   {
     "mcpServers": {
       "local-fastapi-mcp": {
         "url": "http://127.0.0.1:8000/mcp"
       }
     }
   }


2. Activation: The server needs to be enabled in Cursor’s settings (Ctrl+, search for “Cursor Settings” and go to the “MCP” tab).
3. Usage: The Cursor agent (in the chat panel) can then be asked to use the discovered tools.

Key Learnings

• uv Basics: uv init, uv venv, and uv pip install provide a fast way to set up a Python project environment.
• fastapi-mcp Initialization Order: The FastApiMCP(app) instance must be created and mcp.mount() must be called after the FastAPI routes (@app.get, etc.) that you want to expose as tools are defined. Otherwise, the tools won’t be discovered.
• Port Conflicts: Background processes (like uvicorn) can hold ports. On Windows, netstat -ano | findstr "<PORT>" can find the Process ID (PID), and taskkill /F /PID <PID> can terminate it. Sometimes a short wait or restarting the IDE is needed for the OS to fully release the port.
• Cursor MCP Configuration: Using the url key in .cursor/mcp.json connects Cursor to HTTP-based MCP servers (like the one provided by fastapi-mcp).
• Agent Tool Invocation: While the general Cursor agent environment uses the configured MCP servers, the specific pair-programming AI assistant interacts with them using automatically generated internal names (e.g., mcp_local-fastapi-mcp_read_root__get) rather than a generic tool-calling function. Explicitly asking the agent in chat to “Use the tool…” works once the connection is established and the tool is discovered.

Further Exploration & Features (from fastapi-mcp docs)

This section summarizes features and concepts from the fastapi-mcp documentation that we haven’t implemented yet but are useful to know.

Authentication & Authorization

fastapi-mcp supports using FastAPI dependencies for auth and also includes OAuth 2 support.

Basic Token Passthrough:

• No special server config needed initially.

• The MCP client needs to send the Authorization header. This can often be done via a bridge like mcp-remote:

  {
    "mcpServers": {
      "remote-example": {
        "command": "npx",
        "args": [
          "mcp-remote",
          "http://localhost:8000/mcp",
          "--header",
          "Authorization:${AUTH_HEADER}"
        ]
      },
      "env": {
        "AUTH_HEADER": "Bearer <your-token>"
      }
    }
  }


• To require auth on the MCP server side, add dependencies to AuthConfig:

  from fastapi import Depends
  from fastapi_mcp import FastApiMCP, AuthConfig

  # Assuming verify_auth is your FastAPI dependency that checks the token
  mcp = FastApiMCP(
      app,
      auth_config=AuthConfig(
          dependencies=[Depends(verify_auth)],
      ),
  )


OAuth 2 Flow:

• Full support for OAuth 2 (MCP Spec 2025-03-26).
• Requires configuring AuthConfig with provider details (issuer, URLs, client ID/secret).
• setup_proxies=True is often needed to handle incompatibilities between standard OAuth providers and MCP client expectations (like missing dynamic registration, scope handling).

  mcp = FastApiMCP(
      app,
      auth_config=AuthConfig(
          issuer=f"https://auth.example.com/",
          authorize_url=f"https://auth.example.com/authorize",
          oauth_metadata_url=f"https://auth.example.com/.well-known/oauth-authorization-server",
          audience="my-audience",
          client_id="my-client-id",
          client_secret="my-client-secret",
          dependencies=[Depends(verify_auth)],
          setup_proxies=True, # Creates compatibility endpoints
      ),
  )


• Using mcp-remote often requires specifying a fixed port (mcp-remote ... 8080) so the callback URL (http://127.0.0.1:8080/oauth/callback) can be configured in the OAuth provider.

Tool Naming

• MCP tool names are derived from the FastAPI route’s operation_id.
• If not specified, FastAPI generates one automatically (e.g., read_user_users__user_id__get).
• It’s recommended to set explicit operation_ids on FastAPI routes for clearer MCP tool names:

  @app.get("/users/{user_id}", operation_id="get_user_info")
  async def read_user(user_id: int):
      # ...


Refreshing Tools

• If FastAPI routes are added after mcp.mount() is called, they won’t be automatically included.

• Solution: Call mcp.setup_server() again after defining the new routes.

  app = FastAPI()
  mcp = FastApiMCP(app)
  mcp.mount()

  @app.get("/new/endpoint", operation_id="new_tool")
  async def new_endpoint(): ...

  # Refresh the tools
  mcp.setup_server()


Testing

• The @modelcontextprotocol/inspector tool can be used to test MCP servers:

  # Run the inspector
  npx @modelcontextprotocol/inspector
  # Connect to your server URL (e.g., http://127.0.0.1:8000/mcp)
  # Use the UI to list and run tools.


Deployment

• You can mount the MCP server created from one FastAPI app (api_app) onto a different FastAPI app (mcp_app) for separate deployment:

  api_app = FastAPI()
  # ... define API endpoints ...

  mcp_app = FastAPI()
  mcp = FastApiMCP(api_app) # Create from api_app
  mcp.mount(mcp_app) # Mount onto mcp_app

  # Run separately:
  # uvicorn main:api_app --port 8001
  # uvicorn main:mcp_app --port 8000


Customization

• Server name/description can be set during FastApiMCP initialization:

  mcp = FastApiMCP(
      app,
      name="My Custom MCP Name",
      description="Description for the server."
  )


• Tool/schema descriptions can be customized (e.g., include all possible responses):

  mcp = FastApiMCP(
      app,
      describe_all_responses=True,
      describe_full_response_schema=True
  )


• Exposed endpoints can be filtered using include_operations, exclude_operations, include_tags, exclude_tags during FastApiMCP initialization.

Acknowledgements

This project was developed with the assistance of AI pair programming tools, including Google’s Gemini model integrated into Cursor and OpenAI’s ChatGPT for research and documentation retrieval. Their contributions were invaluable throughout the process.
